Mitsubishi HG-KR43K - Servo Motors
The Mitsubishi HG-KR43K Servo Motor supports defined motion performance with its 0.4 kW capacity and low inertia characteristics for automation requirements. The HG-KR43K belongs to the Mitsubishi servo family and provides 1.3 Nm rated torque, 4.5 Nm maximum torque, 3000 rpm rated speed, 6000 rpm maximum speed, IP65 protection, a 22-bit encoder, and a keyway shaft. This Servo Motor is part of the Mitsubishi Servo Motors range and aligned with the MELSERVO-J4 Series for dependable industrial operation.
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-KR43K |
Mitsubishi Servo Motors HG-KR43K Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-J4 |
| Type | HG-KR |
| Power Supply (V) | 200 |
| Rated Capacity (kW) | 0,4 |
| Inertia | LOW INERTIA |
| Rated Torque (Nm) | 1,3 |
| Maximum Torque (Nm) | 4,5 |
| Rated Speed (rpm) | 3000 |
| Inertia (kg*cm2) | 371 |
| Brake | NO |
| Shaft Type | KEYWAY |
| Current Type | AC |
| Encoder Resolution (p/rev) | 4194304 |
| Maximum Speed (rpm) | 6000 |
| Protection Class | IP65 |
| Encoder Type | 22-BIT |
| Depth (mm) | 98,3 |
| Weight (kg) | 1,4 |
| Width (mm) | 60 |
| Height (mm) | 77,1 |
The Mitsubishi HG-KR43K Servo Motor delivers defined rotation control with 0.4 kW capacity, 1.3 Nm torque, and 3000 rpm speed. The HG-KR43K is part of the MELSERVO-J4 Series and features IP65 housing, a 22-bit encoder, and a keyway shaft. This Servo Motor supports industrial automation systems requiring accurate positioning and stable torque behavior.
The Mitsubishi HG-KR43K Servo Motor is used in conveyors, assembly stations, pick-and-place units, packaging machines, and compact robotic mechanisms. Its low inertia improves acceleration response, while the encoder resolution supports repeatable accuracy in cycle-based motion. The AC drive compatibility and shaft configuration enable easy integration into various machine layouts.
The Mitsubishi HG-KR43K Servo Motor combines its torque capability, encoder accuracy, and protection class to maintain consistent industrial performance. As part of the MELSERVO-J4 ecosystem, the HG-KR43K supports continuous-duty environments that require predictable rotation and reliable feedback. Mitsubishiβs servo design consistency makes this model a suitable choice for long-term machine operation.
