Mitsubishi HG-JR9034 - Servo Motors
The Mitsubishi HG-JR9034 Servo Motor delivers 9 kW output, 28.6 Nm torque, and 3000 rpm rated speed with a low inertia configuration. It supports a maximum speed of 5000 rpm and uses a 22-bit encoder providing 4194304 p/rev resolution for stable feedback. The motor features IP67 protection, AC operation, a straight shaft design, and a weight of 36 kg suitable for industrial machinery. Explore Mitsubishi, review Mitsubishi Servo Motors, and see its position within the MELSERVO-J4 series.
| Brand | Mitsubishi |
| Product Type | Servo Motors |
| Product | HG-JR9034 |
Mitsubishi Servo Motors HG-JR9034 Technical Specifications:
| Specification | Value |
|---|---|
| Series | MELSERVO-J4 |
| Type | HG-JR |
| Power Supply (V) | 400 |
| Rated Capacity (kW) | 9 |
| Inertia | LOW INERTIA |
| Rated Torque (Nm) | 28,6 |
| Maximum Torque (Nm) | 85,8 |
| Rated Speed (rpm) | 3000 |
| Inertia (kg*cm2) | 55,8 |
| Brake | NO |
| Shaft Type | STRAIGHT SHAFT |
| Current Type | AC |
| Encoder Resolution (p/rev) | 4194304 |
| Maximum Speed (rpm) | 5000 |
| Protection Class | IP67 |
| Encoder Type | 22-BIT |
| Depth (mm) | 382,5 |
| Weight (kg) | 36 |
| Width (mm) | 176 |
| Height (mm) | 251,3 |
The Mitsubishi HG-JR9034 Servo Motor is a 9 kW low inertia AC servo designed for precise and dependable industrial motion control. It provides 28.6 Nm torque, a 3000 rpm rated speed, and encoder resolution of 4194304 p/rev using a 22-bit feedback system. As part of the MELSERVO-J4 series, the model supports high-performance automation environments requiring stable acceleration and repeatable torque delivery.
This servo motor is suitable for conveyors, packaging systems, assembly lines, and high-load automation equipment. The low inertia design enables rapid speed changes, making it effective in applications requiring fast response and controlled deceleration. Its IP67 protection rating and straight shaft design provide compatibility and durability in industrial production areas exposed to dust or moisture.
The Mitsubishi HG-JR9034 Servo Motor offers consistent performance, accurate position feedback, and reliable torque handling across various automation processes. Its MELSERVO-J4 platform ensures compatibility with industrial control systems while maintaining dependable operation under continuous load. Engineers can rely on this model for stable, repeatable, and long-term industrial motion control requirements.
