Mitsubishi FX3U-4DA-ADP - PLC Analog Output Module
The Mitsubishi FX3U-4DA-ADP Programmable Logic Controller includes 4 analog output channels supporting 0–10V voltage and 4–20mA current ranges for precise signal control. Developed by Mitsubishi, this module belongs to the Mitsubishi Programmable Logic Controller category and is part of the MELSEC-F Series. It operates on a 24V DC supply, measures 90 mm height, 17.6 mm width, 89.5 mm depth, weighs 0.1 kg, and functions up to 55°C.
| Brand | Mitsubishi |
| Product Type | PLC Analog Output Module |
| Product | FX3U-4DA-ADP |
Mitsubishi PLC Analog Output Module FX3U-4DA-ADP Technical Specifications
| Specification | Value |
|---|---|
| Series | MELSEC-F SERIES |
| Type | FX3U |
| Depth (mm) | 89,5 |
| Weight (kg) | 0,1 |
| Width (mm) | 17,6 |
| Height (mm) | 90 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Analogue Outputs | 4 |
| Output Voltage Range (V) | 0-10 |
| Output Current Range (mA) | 4-20 |
| Max. Ambient Temperature (°C) | 55 |
The Mitsubishi FX3U-4DA-ADP Programmable Logic Controller is a compact analog output module within the MELSEC-F Series. It provides 4 analog output channels with 0–10V and 4–20mA ranges, operating on a 24V DC supply. The module’s slim design and stable performance make it ideal for accurate signal control in industrial automation systems.
The Mitsubishi FX3U-4DA-ADP PLC module is used in applications such as process control, conveyors, and assembly lines where precise analog output is essential. Its DC-powered operation ensures consistent output for controllers and actuators, helping engineers maintain smooth performance across automated machinery. The unit integrates seamlessly with Mitsubishi PLC setups, supporting reliable analog signal conversion and scalable control expansion.
The Mitsubishi FX3U-4DA-ADP Programmable Logic Controller delivers accurate, stable, and repeatable analog output for industrial control systems. With 4 output channels and compatibility with the MELSEC-F Series, it supports continuous automation across diverse environments. Built with Mitsubishi’s engineering reliability, this module ensures efficient analog control, long operational life, and dependable performance for industrial buyers and automation integrators.
