Mitsubishi FX2N-8AD - PLC Analog Output Module
The Mitsubishi FX2N-8AD Programmable Logic Controller includes 8 analog input channels supporting 0–20mA and 4–20mA current ranges for precision signal acquisition. Developed by Mitsubishi, it belongs to the Mitsubishi Programmable Logic Controller family within the MELSEC-F Series. Operating on a 24V DC power supply, this module measures 105 mm in height, 75 mm in width, and 75 mm in depth, with a durable build weighing 0.4 kg for reliable industrial performance.
| Brand | Mitsubishi |
| Product Type | PLC Analog Output Module |
| Product | FX2N-8AD |
Mitsubishi PLC Analog Output Module FX2N-8AD Technical Specifications
| Specification | Value |
|---|---|
| Series | MELSEC-F SERIES |
| Type | FX2N |
| Occupied I/O Points on PLC | 8 |
| Integrated Analogue Inputs | 8 |
| Input Current Range (mA) | -20-20; 4-20 |
| Depth (mm) | 75 |
| Weight (kg) | 0,4 |
| Width (mm) | 75 |
| Height (mm) | 105 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Max. Ambient Temperature (°C) | 55 |
| Input Voltage Range (V) | -20 |
The Mitsubishi FX2N-8AD Programmable Logic Controller is a compact analog input module from the MELSEC-F Series. It provides 8 analog inputs supporting both 0–20mA and 4–20mA current ranges, operating efficiently on 24V DC power. Designed with robust construction, it ensures accurate signal measurement and stable performance in automation systems requiring high-precision data input.
The Mitsubishi FX2N-8AD PLC is widely used in industrial automation, including assembly lines, process control, and equipment monitoring. It enables accurate analog signal collection for sensors and transducers, allowing seamless communication with control units for efficient operation and process optimization.
The Mitsubishi FX2N-8AD Programmable Logic Controller upholds Mitsubishi’s quality and reliability standards within the MELSEC-F Series. With 8 input channels and support for 4–20mA current signals, it delivers dependable analog data acquisition for industrial automation applications. Compact, efficient, and reliable, it provides consistent performance in modern process control environments across India.
