Mitsubishi Variable Frequency Drive FR-F840-01160-E2-60 Technical Specifications:
Specification
Value
Series
FR-F800 SERIES
Type
FR-F800-E INVERTER
Minimum Rated Voltage (V)
380
Min. Permissible Voltage (V)
323
Maximum Rated Voltage (V)
500
Max. Permissible Voltage (V)
550
Current Type
AC
Phases
3
Frequency Range (Hz)
0,2–590
Control Method
V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type
INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter
YES
Display
FR-DU08
Display Type
5 DIGITS LED (12 SEGMENT)
Program Memory
6K
Program Memory Unit
STEPS
Integrated Digital Inputs
12
Digital Outputs (Transistor)
5
Digital Outputs (Relay)
2
Depth (mm)
250
Width (mm)
435
Height (mm)
550
Protection Class
IP00
Weight (kg)
41
Send Your Inquiry for Variable Frequency Drive FR-F840-01160-E2-60 with cost-effective solutions. Essential Technical Specs of FR-F840-01160-E2-60 are FR-F800-E INVERTER from the FR-F800 SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 323V, a maximum rated voltage of 500V, and a maximum permissible voltage of 550V. It is designed with an IP00 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 250 mm, a width of 435 mm, and a height of 550 mm, making it suitable for space-constrained installations. It weighs 41 kg, ensuring easy handling and installation. Capture the Best Deal with a Quote for your requirement of Variable Frequency Drive. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
