Leuze MSI-TR1B-02 | 547959
Technical Specifications of Leuze MSI-TR1B-02 547959:
| Brand | Leuze |
| Product Type | Safety Relay |
| Product | MSI-TR1B-02 |
Leuze Periodic Function Safety Relay MSI-TR1B-02, 547959 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 111 mm x 114.1 mm |
| Functions | "Error" signal output "Safety ON" signal output Contactor monitoring (EDM) Periodic function test Start/restart interlock (RES) |
| Restart | Automatic Manual |
| Type of Terminal | Spring-cage terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Connection to device Voltage supply |
| Number of connections | 1 Piece(s) |
| Response Time | 20 ms |
| Evaluation of the inputs | - |
| Input current | - |
| Supply Voltage UB | 24 V, DC, -20 ... 20 % |
| Power consumption, max | 4.8 W, For 24 V, plus output load |
| Switching Output 1 | Transistor, PNP |
| Type of fastening | Snap-on mounting |
| Housing Material | Plastic |
| Housing Color | Gray |
| Ambient Temperature, Operation | -30 ... 60 °C |
| Ambient Temperature, Storage | -40 ... 70 °C |
| Degree of protection | IP 40 |
Reach Us by Email for Leuze Periodic Function Safety Relay MSI-TR1B-02 547959 at Discounted Rates. Key Technical Features of MSI-TR1B-02 are 22.5 mm x 111 mm x 114.1 mm, error and safety signal outputs, contactor monitoring, periodic function tests, and start/restart interlock options. Equipped with spring-cage terminals and PNP transistor output, it provides reliable performance in a wide temperature range (-30 to 60°C) and offers IP 40 protection. Navigate Your Needs with a Quote for your requirement of Leuze Periodic Function Safety Relay. Our pricing and support are unrivaled, especially when compared to other Competitors.
