Leuze LS328I/9D-200-M12 Photoelectric Sensor
The Leuze LS328I/9D-200-M12 Photoelectric Sensor (Part No: 50144556 ) offers a Throughbeam principle, 0 ... 23 m operating range, PUR 200 mm cable with M12 connector 4-wire and 4-pin . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS 5 Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LS328I/9D-200-M12 |
Leuze LS328I/9D-200-M12 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 328 Series |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0 ... 23 m |
| Light source | LED, Infrared |
| Wavelength | 850 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 15 mA |
| Readiness delay | 300 ms |
| Connection Function | Signal IN Voltage supply |
| Type of Connection | PUR 200 mm cable with M12 connector |
| Number of conductors or Pins | 4-wire and 4-pin |
| Dimension | 18 mm x 46 mm |
| Housing material | Plastic: ABS Stainless steel: V2A |
| Lens cover material | Plastic |
| Housing color | Black, Silver |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67 |
| Net weight | 20 g |
Send Us an Email for Leuze 46mm M12 Connector Transmitter Sensor LS328I/9D-200-M12 part no: 50144556 at the lowest pricing. Technical Specs Summary of LS328I/9D-200-M12, 50144556 includes 328 series, Throughbeam, Transmitter device, 0 ... 23 m operating range, LED, Infrared light source, 850 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 15 mA current, PUR 200 mm cable with M12 connector, 4-wire and 4-pin, 18 mm x 46 mm dimensions, Black, Silver housing color, LED display, IP 67 degree of protection. Capture the Best Deal with a Quote for your requirement of Leuze 46mm M12 Connector Transmitter Sensor. Our promise: More affordable pricing and more personalized support than other Competitors.
