Leuze LE49CI.UC/TS-TB Photoelectric Sensor
The Leuze LE49CI.UC/TS-TB Photoelectric Sensor (Part No: 50127445 ) offers a 0 ... 120 m operating range, Relay, NC/ Relay, NO output, Spring-cage terminal 5 -pin . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LE49CI.UC/TS-TB |
Leuze LE49CI.UC/TS-TB Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 49C Series |
| Operating principle | Throughbeam principle |
| Device type | Receiver |
| Operating range | 0 ... 120 m |
| Power Supply | 20 ... 250 V, AC/DC |
| Open-circuit current | - |
| Number of digital switching outputs | 2 Piece(s) |
| Switching Output | Relay, NC/ Relay, NO |
| Switching Principle | Light switching |
| Switching frequency | 25 Hz |
| Response time | 20 ms |
| Readiness delay | 300 ms |
| Connection Function | Signal OUT Voltage supply |
| Type of Connection | Spring-cage terminal |
| Number of conductors or Pins | 5 -pin |
| Dimension (W x H x L) | 31 mm x 104 mm x 55.5 mm |
| Housing material | Plastic: PC |
| Lens cover material | Plastic |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature | operation -40 ... 60 °C storage -40 ... 70 °C |
| Degree of protection | IP 67 |
| Net weight | 150 g |
Please speak to our Technical Engineer for Leuze Relay NO/NC Output Receiver Sensor LE49CI.UC/TS-TB part no: 50127445 at economical prices. Essential Technical Specs of LE49CI.UC/TS-TB, includes 49C series, Throughbeam principle
, Receiver device, 20 ... 250 V, AC/DC
power supply, - current, 2 Piece(s) digital switching output, Relay, NC/ Relay, NO output, Light switching, 25 Hz frequency, Spring-cage terminal, 5 -pin, 31 mm x 104 mm x 55.5 mm dimensions, Red housing color, LED
display, IP 67 degree of protection. Capture the Best Deal with a Quote for your requirement of Leuze Relay NO/NC Output Receiver Sensor.
