Increased chemical resistance; Extended male piston rod thread; Piston rod with female thread; Custom thread on the piston rod; Piston rod with male thread shortened at one end; Extended piston rod; Axial supply port; Uniform, slow movement; Low friction; Piston rod at one end
Operating pressure
1.2; 10
Mode of operation
Pushing; Single-acting
Operating medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium
Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC
2 - Moderate corrosion stress
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Ambient temperature
-20; 120
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke
