VFD11AME21ANNAA : Delta VFD 230V Single-phase
The Technical Specifications of Delta VFD 230V Single-phase VFD11AME21ANNAA:
- Series: ME300
- Input Voltage: 230V Single-phase
- Motor Output (kW): 2.2 kW
- Motor Output (HP): 3 HP
- Cooling Method: Fan Cooling
- Braking Chopper: Built-in
Delta VFD 230V Single-phase VFD11AME21ANNAA Technical Specifications:
| Series Name | ME300 |
| Input Voltage / Frequency | Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 2.2 kW |
| Applicable Motor Output (HP) | 3 HP |
| Heavy Duty Rated Output Current | 11 A |
| Normal Duty Rated Output Current | 12.5 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | None |
| Safe Torque Off (STO) | None |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0 to 599.00 Hz |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W × H (mm) | 87 x 157 |
| Size: D (mm) | 163 |
| Net Weight | 1 kg |
IndMALL offers the Delta VFD11AME21ANNAA, a high-performance Delta VFD 230V single-phase series ME300, featuring a 2.2 kW (3 HP) motor output, efficient fan cooling, and a built-in braking chopper for enhanced control.
