VFD055E43C: Delta 7.5HP 460V 3-Phase CANopen
Technical Specifications of Delta 7.5HP 460V 3-Phase CANopen VFD055E43C:
| Spec | Value |
|---|---|
| Input Voltage / Frequency | 460V Three-phase, 380-480V, 50/60Hz |
| Applicable Motor Output ( kW) | 5.5 kW |
| Applicable Motor Output (HP) | 7.5 HP |
| Output Capacity (kVA) | 9.9 kVA |
Delta 7.5HP 460V 3-Phase CANopen VFD055E43C Technical Specifications:
| Specification | Value |
|---|---|
| Series Name | E |
| Input Voltage / Frequency | 460V Three-phase, 380-480V, 50/60Hz |
| Applicable Motor Output ( kW) | 5.5 kW |
| Applicable Motor Output (HP) | 7.5 HP |
| Output Capacity (kVA) | 9.9 kVA |
| Output Current (A) | 13 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| Pollution Degree | 2 |
| Storage/Transportation Temperature | -20ºC to 60ºC |
| Ambient Humidity | Below 90% RH (non-condensing) |
| V/F Pattern | Adjustable V/F pattern |
| Version Type | C: CANopen |
| Input Frequency Tolerance | ±5% (47-63Hz) |
| Voltage Tolerance | ±10% (342-528V) |
| Net Weight (kg) | 4.2 kg |
Call us for Delta 7.5HP 460V 3-Phase CANopen, VFD055E43C at the best rates. Technical Attributes of VFD055E43C are Below 90% RH (non-condensing), Adjustable V/F pattern, C: CANopen & IP20. And It Delivers 5.5 kW, 7.5 HP & 9.9 kVA.Unlock Exclusive Pricing with a Quote for your requirement of Delta 7.5HP 460V 3-Phase CANopen. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
