Delta PMT-24V50W2BA 24V 2.2A Panel Mount Power Supply
The Delta PMT-24V50W2BA Power Supply is a compact panel mount unit designed for stable DC output in industrial control systems. It delivers 24V output with 2.2A current and 53W power, supporting reliable operation across automation panels and electrical enclosures. The unit operates on a wide input range of 90–264VAC with 50–60Hz frequency support, ensuring compatibility with standard power conditions. It features adjustable output voltage between 21.6–26.4VDC and maintains consistent efficiency under full load. Manufactured by Delta automation, it belongs to the power supply category used in industrial applications.
| Brand | Delta |
| Product Type | SMPS |
| Product | PMT-24V50W2BA |
Delta 2.2A 24V Panel Mount Power Supply PMT-24V50W2BA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 2.2A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 21.6-26.4Vdc |
| Output Power | 53W |
| Start-up Time | 1,000ms typ. @ 115Vac 500ms typ. @ 230Vac |
| Hold-up Time | 12ms typ. @ 115Vac, 60ms typ. @ 230Vac |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 90-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| Input Current | 0.95A typ. @ 115Vac, 0.55A typ. @ 230Vac |
| Efficiency at 100% load | 88.0% typ. @ 230Vac |
| Leakage Current | < 0.5mA @ 240Vac |
| Case Chassis / Cover | SGCC / Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Unit Weight | 0.176 kg (0.39 lb) |
| Operating Temperature | -30°C to +70°C (-40°C Cold Start) |
| Storage Temperature | -40°C to +85°C |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) |
| Pollution Degree | 3 |
| Over Voltage Category | II (Compliance to EN 62477-1 OVC III with 2000 meters altitude) |
The Delta PMT-24V50W2BA is built for stable performance in panel-based installations where consistent DC supply is required for controllers, relays, and automation components. Its compact construction and lightweight design allow easy integration into control panels without adding space constraints. The green LED indicator provides clear status feedback, helping maintain system visibility during operation.
The unit maintains steady output across varying load conditions and supports a wide input voltage range, making it suitable for different industrial power environments. Adjustable output voltage provides flexibility during setup, while efficient power conversion helps reduce energy loss during continuous use. The convection cooling design ensures reliable heat dissipation without requiring additional cooling components.
From an application perspective, the Delta PMT-24V50W2BA fits systems that demand reliable 24V DC distribution with minimal maintenance. Its ability to operate across wide temperature and altitude conditions supports long-term usage in industrial environments. This structured combination of power stability, compact design, and environmental compatibility makes it a practical solution for panel-mounted power supply applications.
