DVP40ES200TE:
Technical Specifications of DVP40ES200TE Delta PLC with Ethernet Communication:
| Spec | Value |
|---|---|
| Output Method | Transistor |
| Power Supply | 100 ~ 240VAC (-15% ~ 10%); 50/60Hz + -5% |
| Number of Inputs and Type | 24 - Digital |
| Number of Outputs and Type | 16 - Transistor |
| Power Consumption | 30VA |
DVP40ES200TE Technical Specifications:
| Specification | Value |
|---|---|
| Output Method | Transistor |
| Power Supply | 100 ~ 240VAC (-15% ~ 10%); 50/60Hz + -5% |
| Number of Inputs and Type | 24 - Digital |
| Number of Outputs and Type | 16 - Transistor |
| Fuse Capacity | 2A/ 250VAC |
| Power Consumption | 30VA |
| Program Capacity | 16k Steps |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage /Operation humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | OFF ON: 2.5μs ON→OFF: 5 μs |
| Vibration/shock resistance | International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 (TEST Ea) |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
Are you looking for the Delta DVP40ES200TE? It is Delta DVP-ES2 Series, operates on a power supply voltage ranging from 100 to 240VAC and uses a transistor output method with a 2A/250VAC fuse capacity. It features 24 digital inputs and 16 transistor outputs, suitable for various applications. The operational temperature range is 0ºC to 55ºC, and it has a program capacity of 16k steps, consuming 30VA of power with a 24VDC ±10% input signal voltage requirement. For competitive prices on Delta PLC, check out IndMALL Automation.
