Delta DVP20EX00T2 Programmable Logic Controller
Delta DVP20EX00T2 Programmable Logic Controller is designed for advanced automation systems where both digital and analog signal control are required. This Delta PLC features integrated digital and analog inputs and outputs, making it suitable for handling combined process and machine control applications. It supports essential program capacity for executing automation logic with stable and accurate performance. Operating on a wide AC power supply range, it integrates easily into industrial control panels. Developed under Delta automation solutions, it belongs to the programmable controller category and is part of the DVP-EX Series PLC used in process and machine-level applications.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP20EX00T2 |
Delta DVP20EX00T2 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Output Method | Transistor&Analog |
| Power Supply | 100 ~ 240VAC (-15% ~ 10%); 50/60Hz + -5% |
| Number of Inputs and Type | 8 Digital & 4 Analog |
| Number of Outputs and Type | 6- Transistor & Analog - 2 |
| Fuse Capacity | 2A/ 250VAC |
| Power Consumption | 30VA |
| Program Capacity | 16k Steps |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage /Operation humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | OFF→ON: 3.5μs ON→OFF: 20μs |
| Vibration/shock resistance | International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 (TEST Ea) |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
The Delta DVP20EX00T2 is built to deliver stable control performance in systems where both digital and analog signal handling are essential. Its combined I/O capability allows accurate monitoring and control of variables such as temperature, pressure, and speed, making it suitable for applications that require mixed signal processing. The controller ensures consistent execution of automation tasks with reliable performance.
In industrial environments, this PLC is widely used in packaging machines, conveyor systems, and small process automation setups where both analog and digital control are required. It enables operators and system integrators to manage input signals, control outputs, and execute programmed sequences efficiently. The design supports continuous operation with stable performance across different machine conditions.
From a system integration perspective, the Delta DVP20EX00T2 fits automation environments that require a compact and versatile control unit with integrated analog and digital I/O. It supports long-term operation under industrial conditions while maintaining stable execution of control tasks. This makes it a practical choice for applications that require efficient automation, flexible integration, and reliable system performance.
