Delta DVP20EH00T3 Programmable Logic Controller
Delta DVP20EH00T3 Programmable Logic Controller is designed for compact automation systems where fast control and stable performance are required. This Delta PLC comes with built-in digital inputs and transistor outputs, making it suitable for applications that demand quick switching and precise signal handling. It supports efficient program execution with extended memory capacity for managing automation logic smoothly. The controller operates on a wide power supply range, allowing easy integration into various control panels. Developed under Delta automation solutions, it belongs to the programmable controller category and is part of the DVP-EH3 Series PLC used in advanced machine-level applications.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP20EH00T3 |
Delta DVP20EH00T3 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Output Method | Transistor |
| Power Supply | 100 ~ 240VAC (-15% ~ 10%); 50/60Hz + -5% |
| Number of Inputs and Type | 12– Digital |
| Number of Outputs and Type | 8– Transistor |
| Fuse Capacity | 2A/250VAC |
| Power Consumption | 50VA |
| Program Capacity | 32K Steps |
| Counters | 2 counters of 200 kHz input, 2 axes of 200 kHz output |
| 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) | Spike Voltage Durability |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage /Operation Humidity | 5%~95% (humidity) 5%~95% (humidity); pollution degree 2 |
| Response Time | OFF→ON: 0.15μs ON→OFF: 3 μs |
| Vibration/shock Resistance | International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 (TEST Ea) |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
The Delta DVP20EH00T3 is built to support reliable and fast control logic in systems where quick response and accurate output switching are essential. Its transistor outputs enable high-speed operation, making it suitable for applications that require precise timing and signal control. The controller is designed to execute automation sequences with stable performance and efficient processing.
In industrial applications, this PLC is used in packaging machines, conveyor systems, and small process setups where fast response and consistent control are required. It enables system integrators to manage input signals, control outputs, and execute programmed logic efficiently. The compact structure supports easy installation within control panels while maintaining strong operational reliability.
From a system integration perspective, the Delta DVP20EH00T3 fits automation environments that require a compact and responsive control unit. It supports long-term operation under industrial conditions while maintaining consistent performance. This makes it a practical choice for applications that require reliable execution of machine control tasks with high-speed output handling.
