DVP04DA-H2: Delta PLC Analog Output Module
The Technical Specifications of Delta PLC Analog Output Module DVP04DA-H2:
- Series: DVP-EH3 series PLC
- Power Supply Voltage: 24V DC
- Analog output channel: 4 channels/module
- Resolution: 12 bits
- Responding time: 3ms
- Range of analog output: 0 ~ 10V
- Max. output current: 10mA (1KΩ ~ 2MΩ)
- Operating Temperature: 0°C ~ 55°C
Delta PLC Analog Output Module DVP04DA-H2 Technical Specifications:
Resolution | 12-bit |
Type | Expansion Module |
Power supply voltage | 24V DC (20.4V DC ~ 28.8V DC) (-15% ~ +20%) |
Analog output channel | 4 channels/module |
Number of Outputs and Type | 4 – Analog |
Range of analog output | 0 ~ 10V or 0 ~ 20mA |
Range of digital data | 0 ~ 4,000 |
Output impedance | 0.5Ω or lower |
Overall accuracy | +0.5% when in full scale (25°C, 77°F) +1% when in full scale within the range of 0 ~ 55°C, 32 ~ 131°F |
Responding time | 3ms × the number of channels |
Max. output current | 10mA (1KΩ ~ 2MΩ) |
Digital data format | 11 significant bits out of 16 bits are available; in 2’s complement |
Protection | Voltage output is protected by short circuit. Short circuits lasting for too long may cause damage to internal circuits. The current output can be an open circuit. |
Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
Storage /Operation humidity | 5%~95% (humidity) 5%~95% (humidity); pollution degree 2 |
Vibration/shock immunity | International standards: IEC 61131-2, IEC 68-2-6 (TEST Fc)/IEC 61131-2 & IEC 68-2-27 (TEST Ea) |
Are you looking for the Delta PLC Analog Output Module DVP04DA-H2? It’s from the DVP-EH3 series and requires 24V DC power. This module offers 4 analog output channels, each with a 12-bit resolution and a 3ms response time. The output range is 0 ~ 10V, supporting a maximum output current of 10mA for loads between 1KΩ and 2MΩ. It operates efficiently in temperatures from 0°C to 55°C. For competitive Delta PLC prices, IndMALL Automation is a great choice.
