Delta DRP012V015W1AZ 1.25A 15W DIN Rail Power Supply
Delta DRP012V015W1AZ is a 12V 15W DIN Rail Power Supply designed for reliable low-power DC distribution in industrial automation and control systems. It delivers a stable 12V DC output with 1.25A current and 15W power, suitable for compact control panels, sensors, and automation modules. The unit supports a nominal input voltage of 100-240Vac and a wide input frequency range of 50-60Hz, ensuring stable operation in varied industrial environments. With a Green LED (DC OK) indicator, operators can quickly monitor the power status. Manufactured by Delta industrial automation, it falls under the Delta power supply solutions category and is part of the Delta DIN Rail CliQ series, optimized for compact and high-efficiency industrial applications.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP012V015W1AZ |
Delta 12V 15W DIN Rail Power Supply DRP012V015W1AZ Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 1.25A |
| Output Voltage | 12V |
| Output Voltage Adjustment Range | 11-14Vdc |
| Output Power | 15W |
| Line Regulation | < 0.5% (@ 85-264Vac input, 100% load) |
| Load Regulation | < 1% (@ 85-264Vac input, 0-100% load) |
| PARD | < 100mVpp |
| Start-up Time | < 2,500ms @ nominal input (100% load) |
| Hold-up Time | > 22ms @ 115Vac, > 110ms @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 85-264Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1KHz) |
| Start-up with Capacitive Loads | 5,000µF Max |
| Rise Time | < 20ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | < 0.37A @ 115Vac, < 0.22A @ 230Vac |
| Efficiency at 100% load | > 84.0% @ 115Vac, > 83.0% @ 230Vac |
| Inrush Current | < 30A @ 115Vac < 65A @ 230Vac |
| Leakage Current | < 1mA @ 240Vac |
| Power Dissipation | 0% load: < 0.3W @ 115Vac, < 0.7W @ 230Vac 100% load: < 2.9W @ 115Vac, < 3.2W @ 230Vac |
| Case Chassis / Cover | Plastic |
| Indicator | Green LED DC OK |
| Cooling System | Convection |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Input/Output Terminal | 5 Pins (Rated 300V/15A) |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input / Output: AWG 20-14 |
| Unit Weight | 0.18 kg (0.40 lb) |
| Operating Temperature | -20°C to +80°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | Vertical / Horizontal: > 50°C de-rate power by 2.5% / °C, > 70°C de-rate power by 4% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 3 times per direction, 18 times in total |
| Vibration (Non-Operating) | IEC60068-2-6, 10Hz to 150Hz @ 50m/S² (5G peak); 90 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft.) |
| Pollution Degree | 2 |
| Over Voltage Category | III According to IEC/EN 62477-1 (clearance and creepage distances) |
The Delta DRP012V015W1AZ 12V 15W DIN Rail Power Supply is ideal for small automation projects, industrial sensors, and control panels where precise low-current DC delivery is critical. Its compact DIN rail design allows easy installation in control cabinets, saving space while providing reliable power. The unit’s 1.25A output ensures that even multiple small devices can operate simultaneously without voltage drops, maintaining system stability. The robust construction allows it to withstand challenging industrial environments, with an operating temperature range from -20°C to +80°C and storage support from -25°C to +85°C. This ensures consistent performance under extreme heat or cold, reducing downtime and maintenance needs.
Designed for safety and efficiency, the DRP012V015W1AZ features M4 x 2 input and output terminals rated for 300V/16A, providing secure and reliable connections. The Green LED (DC OK) indicator simplifies monitoring, enabling maintenance teams to quickly confirm the unit’s operational status. Its broad input voltage compatibility (85-264Vac) and input frequency tolerance (47-63Hz) allow integration in regions with voltage fluctuations, protecting connected devices and improving system reliability. Engineers and system integrators can confidently deploy this power supply in automation racks, sensor networks, and industrial controllers requiring stable low-power DC.
For industries and OEMs seeking a compact, reliable, and efficient power supply, the Delta DRP012V015W1AZ stands out as a premium solution. It combines high efficiency, durable design, and consistent 12V DC output, supporting continuous operation in demanding conditions. IndMALL provides easy access to this power supply at competitive pricing, along with dedicated support for installation guidance, troubleshooting, and after-sales service. Securing this unit ensures uninterrupted power to automation systems, enhances equipment longevity, and simplifies maintenance, making it an indispensable component for industrial automation and control applications.
