Delta DRP-24V120W2BN 5A 120W DIN Rail Power Supply
Delta DRP-24V120W2BN is a 5A 120W DIN Rail Power Supply engineered for industrial automation systems, control cabinets, and embedded devices requiring dependable DC output. Supporting both 2-phase and single-phase operation with nominal input voltages of 2 x 200-500Vac (2-phase) and 200-277Vac (single-phase), it provides flexibility for diverse industrial setups. Its broad input range of 2 x 180-550Vac (2-phase) and 180-305Vac (single-phase) ensures reliable performance across variable conditions. The compact DIN Rail mounting simplifies installation in control panels. Manufactured by Delta industrial automation, this model is part of the Delta power supply solutions category and belongs to the Delta DIN Rail CliQ II Series, delivering stable 24V DC power to automation systems, process control equipment, and embedded electronics.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRP-24V120W2BN |
Delta 5A 120W DIN Rail Power Supply DRP-24V120W2BN Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 5A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 24-28Vdc |
| Output Power | 120W |
| Line Regulation | < 0.5% (@ 200-550Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 200-550Vac input, 0-100% load) |
| PARD | < 150mVpp |
| Start-up Time | < 2,500ms @ nominal input (100% load) |
| Hold-up Time | > 10ms @ 2 x 230Vac, > 50ms @ 2 x 400Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 180-550Vac input, 0-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 1KHz) |
| Start-up with Capacitive Loads | 5,000µF Max |
| Rise Time | < 70ms @ nominal input (100% load) |
| Nominal Input Voltage | 2 x 200-500Vac (2-Phase) 200-277Vac (Single Phase) |
| Input Voltage Range | 2 x 180-550Vac (2-Phase) 180-305Vac (Single Phase) |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 254-780Vdc |
| Input Current | < 1.20A @ 2 x 230Vac, < 0.80A @ 2 x 400Vac |
| Efficiency at 100% load | > 90.0% @ 2 x 400Vac |
| Inrush Current | < 50A @ 2 x 200Vac |
| Power Factor at 100% load | - |
| Leakage Current | < 1mA @ 500Vac |
| Power Dissipation | 0% load: < 1.7W @ 2 x 200Vac, < 3.2W @ 2 x 500Vac 100% load: < 17W @ 2 x 200Vac, < 15W @ 2 x 500Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Input Terminal | 3 Pins (Rated 600V/35A) |
| Output Terminal | 4 Pins (Rated 300V/28A) |
| Noise Sound Pressure Level (SPL) | < 40dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 18-8 Output: AWG 18-12 |
| Unit Weight | 0.62 kg (1.37 lb) |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | Vertical: > 60°C de-rate power by 4% / °C Horizontal: > 50°C de-rate power by 4% / °C Input Voltage: < 200Vac de-rate power by 2% / Vac Cold Start: < -10°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms, 3 times per direction, 6 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, 10Hz to 500Hz @ 30m/S² (3G peak); 60 min per axis for all X, Y, Z direction |
| Operating Altitude | 0 to 2,500 Meters (8,200 ft.) for ITE application (@ 60°C) 0 to 2,000 Meters (6,560 ft.) for Industrial application (@ 60°C) |
| Pollution Degree | 2 |
| Bump Test (Operating) | IEC 60068-2-29, Half Sine Wave: 10G for a duration of 11ms, 1,000 times per direction, 6,000 times in total |
| Over Voltage Category | III According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
The Delta DRP-24V120W2BN 5A 120W DIN Rail Power Supply is ideal for industrial control cabinets, automation panels, and embedded devices requiring consistent 24V DC output. Its 5A current rating and 120W power capacity provide stable power for multiple devices while maintaining efficiency and operational stability. The wide input voltage compatibility ensures uninterrupted performance even under varying industrial power conditions.
Equipped with secure input and output terminals rated for 600V/35A and 300V/28A, this DIN Rail unit allows fast, reliable connections. The Green LED DC OK indicator provides visual confirmation of operational status, simplifying monitoring and maintenance. Compact design ensures organized installation in control cabinets, while the operating temperature range from -30°C to +70°C and storage range of -40°C to +85°C ensures reliability in harsh industrial environments.
Engineers, system integrators, and industrial operators seeking dependable 5A 120W DIN Rail solutions will benefit from the Delta DRP-24V120W2BN’s consistent output, energy efficiency, and industrial-grade durability. IndMALL offers competitive pricing, instant quotes, and responsive support, providing superior value over other suppliers. Its robust construction, compact size, and reliable performance make it ideal for industrial automation, embedded electronics, and process control applications, reducing downtime, improving productivity, and ensuring long-term operational efficiency.
