Delta DOP-107WV 7 Inch HMI Touch Panel
The Delta DOP-107WV Human Machine Interface is designed as a graphical operator panel for process visualization and touch-based interaction in industrial automation systems. It features a 7-inch TFT LCD display with 800 Γ 480 resolution and LED backlight, ensuring clear visibility during continuous operation. This model is commonly used as a Delta 7 inch HMI for machine interfaces where reliable display and touch control are required. It also aligns with applications that consider standard Delta 7 inch HMI dimensions for panel integration. Manufactured by Delta automation, it is part of the HMI product range and belongs to the DOP-100 series panels used across industrial systems.
| Brand | Delta |
| Product | HMI |
| Model Number | DOP-107WV |
Delta DOP-107WV Human Machine Interface - Technical Specifications:
| Specification | Value |
|---|---|
| Display | 7" TFT LCD |
| Color | 16-bit |
| Resolution (Pixels) | 800 x 480 |
| Back Light | LED Back Light |
| Back Light Brightness (cd/m2 ) | 450 |
| Back Light Life (Hour)*1 | 20,000 |
| Display Area | 154.08 x 85.92 mm |
| MCU | ARM Cortex-A8 (800 MHz) |
| Flash ROM (Bytes) | 256 MB |
| RAM (Bytes) | 512 MB |
| Touch Panel | Four-wire resistor, over 10,000,000 pressing times |
| Buzzer | Multi-Tone Frequency (2K ~ 4K Hz) / 80 dB |
| Ethernet Interface | 1 Port*2, 10/100 Mbps auto-sensing |
| USB | 1 USB Slave Ver 2.0 / 1 USB Host Ver 2.0 |
| SD | N / A |
| Serial COM1/2/3/4 Port | COM1 RS-232 (supports hardware flow control)*2, COM2:RS-232 (supports hardware flow control) / RS-485*2, COM3: RS-422 / RS-485*2 |
| RTC | Built-in |
| Cooling | Natural air circulation |
| Certification | CE / UL (please use shielding Ethernet cables and magnetic rings with filters of 300 ohm / 100 MHz) |
| Waterproof | IP65 / NEMA4 / UL Type 4X (indoor use only) |
| Operation Voltage*3 | DC +24V (-15% ~ 15%)*2, supplied by Class 2 or SELV circuit (isolated from MAINS by double insulation) |
| Voltage Endurance | AC500 V for 1 minute (between charging DC24 terminal and FG terminals) |
| Power Consumption*5 | Max. 8.4 W*3 |
| Backup Battery | 3V lithium battery CR2032 Γ 1 |
| Backup Battery Life | Depends on the temperature used and the conditions of usage, usually about 3 years or more at 25 o C |
| Operation Temperature | 0 oC ~ 50 o C |
| Storage Temperature | -20 oC ~ 60 oC |
| Ambient Humidity | 10% ~ 90% RH (0 ~ 40 oC), 10% ~ 55% RH (41 ~ 50 oC), Pollution Degree 5 |
| Viberation | IEC 61131-2 compliant 5 Hz ~ 8.3 Hz = Continuous: 3.5 mm, 8.3 Hz ~ 150 Hz = Continuous: 1 g |
| Shock | IEC 60068-2-27 compliant 15 g peak for 11 ms duration, X, Y, Z, directions for 6 times |
| Dimensions (W) x (H) x (D) mm | 196 x 136 x 39 |
| Mounting Dimensions (W) x (H) mm | 186.8 x 126.8 |
| Weight | 560 g |
The Delta DOP-107WV is built for efficient operator interaction in industrial control panels. It supports touch-based input and real-time monitoring, making it suitable for machines that require a responsive and compact interface. Engineers selecting a Delta 7 inch HMI typically consider this model for its display clarity, stable operation, and ease of integration into automation systems.
In practical applications, this unit performs as a dependable 7 inch HMI panel, maintaining consistent display quality and touch response during continuous operation. It fits standard panel requirements where display size, layout compatibility, and user interaction play a critical role in system performance.
From a selection perspective, the DOP-107WV aligns with typical 7 inch HMI requirements used in automation projects. Buyers evaluating options based on Delta 7 inch HMI dimensions often consider this model for its durability, screen performance, and long-term reliability. This clear relationship between model, display size, and application makes it a practical choice within industrial HMI systems.
