Contrinex DW-AD-713-M18 20 mm Inductive Sensor
DW-AD-713-M18 is a Contrinex 20 mm Inductive Sensor with 20 mm operating range and PNP output for industrial automation. Manufactured by Contrinex, this Contrinex Inductive Sensor from the DW Series supports 10–30 V DC supply, 200 Hz switching frequency, IO-Link interface, IP68/IP69K protection, M18 stainless-steel V2A housing, non-embeddable mounting, and PUR 2 m cable connection.
| Brand | Contrinex |
| Product Type | Inductive Sensor |
| Model Number | DW-AD-713-M18 |
Contrinex DW-AD-713-M18 20 mm Inductive Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Operating range | 20 mm |
| Switching frequency max. | 200 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Normally Open (NO)/IO-Link |
| Connection | PUR, 2 m, 3 wire |
| Housing size [mm] | M18 |
| Enclosure rating | IP 68 / IP 69K |
| Housing material | Stainless-steel V2A |
| Temperature range | -25...+85°C |
| Sensor Height | 51 mm |
| Mounting | Non-embeddable |
| Interface | IO-Link |
| Operating pressure [bar] | ≤ 60 bar |
The Contrinex DW-AD-713-M18 20 mm Inductive Sensor is a defined proximity sensing device used in industrial automation applications. This model operates with a 20 mm sensing distance, PNP normally open output, and a 10–30 V DC supply range. It also includes IO-Link communication for consistent data access and diagnostics. The sensor belongs to the DW Series and is applied where stable metal detection is required.
In industrial environments, the DW-AD-713-M18 Contrinex 20 mm Inductive Sensor is installed on conveyors, packaging systems, automated assembly lines, and material handling equipment. Its non-embeddable M18 construction supports reliable target detection, while the defined switching frequency enables accurate positioning and counting. The IP68/IP69K enclosure and stainless-steel housing allow continued operation in washdown areas and demanding factory conditions.
The DW-AD-713-M18 is a clearly specified inductive sensing solution aligned with DW Series mechanical and electrical parameters. Its operating range, output behavior, and IO-Link interface support long-term use in Indian industrial automation systems. Contrinex maintains consistent manufacturing standards, making this model suitable for applications requiring dependable proximity detection with defined and repeatable performance characteristics.
