EPP9022-0060 - Beckhoff Industrial Housing
Technical Specifications of Beckhoff Industrial Housing EPP9022-0060:
| Brand | Beckhoff |
| Product Type | Industrial Housing |
| Product | EPP9022-0060 |
EPP9022-0060 Beckhoff Industrial Housing Technical Specifications
| Specification | Value |
|---|
| Protocol | EtherCAT P |
| Bus interface | M8 socket, P-coded, shielded |
| Current consumption from US | typ. 100 mA |
| Operating temperature | -25...+60°C |
| Storage temperature | -40...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Housing - Dimensions (W x H x D) | 30 mm x 86 mm x 22 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3 |
| Special features | diagnostic LED for US, diagnostic LED for UP |
| Weight | approx. 90 g |
| Number of channels | IN: 1 x EtherCATÂ P, OUT: 1 x EtherCATÂ P |
| Nominal voltage | 24 V DC (-15%/+20%) |
