EPP6090-0000 - Beckhoff Industrial Housing
Technical Specifications of Beckhoff Industrial Housing EPP6090-0000:
| Brand | Beckhoff |
| Product Type | Industrial Housing |
| Product | EPP6090-0000 |
EPP6090-0000 Beckhoff Industrial Housing Technical Specifications
| Specification | Value |
|---|
| Protocol | EtherCAT |
| Current consumption from US | typ. 130 mA + sensor supply |
| Operating temperature | 0..55°C |
| Storage temperature | -25...+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL (in preparation) |
| Housing - Dimensions (W x H x D) | 60 mm x 126 mm x 26.5 mm |
| Housing - Material | PA6 (polyamide) |
| Housing - Installation | 2 fixing holes 3.5 mm diameter for M3; 2 fixing holes 4.5 mm diameter for M4 |
| Weight | approx. 230 g |
