EL6631-0010 - Beckhoff EtherCAT Communication Interface
EL6631-0010 Beckhoff EtherCAT Communication Interface Technical Specifications
| Brand | Beckhoff |
| Product Type | EtherCAT Communication Interface |
| Product | EL6631-0010 |
EL6631-0010 Beckhoff EtherCAT Communication Interface Technical Specifications
| Specification | Value |
|---|
| Technology | PROFINET RT |
| Power supply | via the E-bus |
| Current consumption E-bus | typ. 400 mA |
| Electrical isolation | 500 V (E-bus/Ethernet) |
| Special features | LLDP, SNMP,Conformance Class B,max. 15 RT devices,min. 1 ms RT cycle |
| Weight | approx. 75 g |
| Operating temperature | 0…55°C |
| Storage temperature | -25…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP20/see documentation |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Ex marking | ATEX:II 3 G Ex ec IIC T4 GcIECEx:Ex ec IIC T4 Gc |
| Housing - Design form | compact terminal housing with signal LEDs |
| Housing - Material | polycarbonate |
| Housing - Dimensions (W x H x D) | 24 mm x 100 mm x 52 mm |
| Housing - Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Housing - Side by side mounting by means of | double slot and key connection |
| Housing - Wiring | specific push-in connection |
| Cable length | up to 100 m twisted pair |
| Configuration | via EtherCAT master |
| Ethernet interface | 100BASE-TX Ethernet with 2 x RJ45 |
| Hardware diagnostics | status LEDs |
| Protocol | RT |
| Number of ports/channels | 2 (switched) |
| Fieldbus | PROFINET RT device |
