CX8180 - Beckhoff Embedded PCs
The CX8180 Beckhoff Embedded PCs feature TwinCAT 3 runtime, passive cooling, and Ethernet communication interface support. The CX8180 is part of Beckhoff Embedded PCs supporting 24 V DC power supply, IP20 protection, automatic E-bus or K-bus recognition, and industrial communication connectivity. This embedded PC belongs to the Beckhoff Embedded PCs category and the CX Series for compact industrial automation control applications.
| Brand | Beckhoff |
| Product Type | Embedded PCs |
| Product | CX8180 |
CX8180 Beckhoff Embedded PCs Technical Specifications
| Specification | Value |
|---|---|
| Processor | Arm ® Cortex ® -A9, 800 MHz |
| Number of cores | 1 |
| Flash memory | slot for microSD card, 512 MB included (optionally expandable) |
| Main memory | 512 MB DDR3 RAM (not expandable) |
| 1-second UPS | integrated (1 MB on microSD card) |
| Interfaces | 1 x RJ45 10/100 Mbit/s, 1 x bus interface |
| Cooling | passive |
| Bus interface | D-sub socket, 9-pin, 1 x RS232, 1 x RS485 |
| Data transfer rates | 300 baudâ¦115 kbaud |
| Diagnostics LED | 1 x TC status, 1 x WD, 1 x error |
| Clock | internal battery-backed clock for time and date (battery behind the front flap, exchangeable) |
| Operating system | Windows Embedded Compact 7 |
| Control software | TwinCAT 3 runtime (XAR) |
| I/O connection | E-bus or K-bus, automatic recognition |
| Power supply | 24 V DC (-15%/+20%) |
| Current supply E-bus/K-bus | 2 A |
| Max. power consumption | 4 W |
| Max. power consumption E-bus/K-bus | 10 W (5 V/max. 2Â A) |
| Dimensions (W x H x D) | 71 mm x 100 mm x 73 mm |
| Weight | approx. 230 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Relative humidity | 95%, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating | IP20 |
| Approvals/markings | CE, UL |
| TwinCAT 3 platform level | Economy (20); please see here for an overview of all the TwinCAT 3 platform level |
The CX8180 Beckhoff Embedded PCs are compact industrial control systems designed for automation and machine communication environments. The CX8180 belongs to the Beckhoff CX Series and supports TwinCAT 3 runtime, 24 V DC operation, passive cooling, and IP20 protection. Beckhoff designed this embedded PC with RJ45 Ethernet connectivity and automatic E-bus or K-bus recognition for industrial automation systems requiring stable communication and distributed control integration. The compact housing dimensions support installation inside industrial control cabinets and decentralized automation panels.
Beckhoff Embedded PCs are used in conveyor systems, packaging equipment, assembly lines, and decentralized automation applications. The CX8180 supports industrial communication through Ethernet and bus interface connectivity for machine monitoring and process coordination tasks. Its passive cooling structure helps maintain dependable operation in industrial environments requiring continuous automation performance. Industrial users integrate these embedded PCs into compact machine control systems requiring stable communication, centralized automation handling, and distributed I/O management across manufacturing operations.
The CX8180 Beckhoff Embedded PCs combine TwinCAT 3 runtime, 24 V DC operation, passive cooling, and automatic E-bus or K-bus recognition for industrial automation systems. Beckhoff CX Series embedded PCs are suitable for machine builders and factory automation applications requiring compact industrial control hardware and reliable communication interfaces. The IP20 protection rating, Ethernet communication support, and low power consumption help maintain stable operation across industrial control, machine integration, and process monitoring environments.
