Baumer UNDK 30P1712/S14: Level Sensors
Technical Specifications of Baumer UNDK 30P1712/S14 10232772:
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
Baumer Level Sensors UNDK 30P1712/S14 Technical Specifications
| Specification | Value |
|---|---|
| Output indicator | LED green |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | Polyester / die-cast zinc |
| Depth | 31 mm |
| Connection types | Connector M12 |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 67 |
| Scanning range Sd | 60 β¦ 400 mm |
| Scanning range far limit Sde | 60 β¦ 400 mm |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Sonic frequency | 400 kHz |
| Adjustment | Potentiometer |
| Residual ripple | < 10 % Vs |
| Width / diameter | 30 mm |
| Height / length | 65 mm |
| Alignment aid | Target indication flashing |
