Baumer UNDK 30P1703 Ultrasonic Sensor
The Baumer UNDK 30P1703 Ultrasonic Sensor offers a Rectangular design, 100 β¦ 1000 mm range, 12 β¦ 30 VDCV supply voltage, PNP make function (NO) output, and Cable, L=2 m connection. Manufactured by Baumer under the Baumer Ultrasonic Sensor category, this model belongs to the UNDK Series.
| Brand | Baumer |
| Product Type | Ultrasonic Sensor |
| Model Number | UNDK 30P1703 |
Baumer UNDK 30P1703 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Scanning range Sd | 100 β¦ 1000 mm |
| Scanning range far limit Sde | 100 β¦ 1000 mm |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,1 % Sde/K |
| Sonic frequency | 240 kHz |
| Adjustment | Potentiometer |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | Polyester / die-cast zinc |
| Width / diameter | 30 mm |
| Height / length | 65 mm |
| Depth | 31 mm |
| Connection types | Cable, L=2 m |
| Operating temperature | -10 β¦ +60 Β°C |
| Protection class | IP 67 |
| Output indicator | LED green |
Call us for Baumer PNP NO Ultrasonic Proximity Sensor UNDK 30P1703 part no: 10233436 at the best rates. Technical Attributes of UNDK 30P1703, 10233436 are scanning range of 100 β¦ 1000 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 240 kHz. It features Potentiometer, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 β¦ 30 VDC and uses a PNP make function (NO) output circuit, supporting an output current of up to 200 mA. Designed in compact Rectangular housing, it measures 30 mm in width and 65 mm in height, making it suitable for various industrial applications. The housing is made from durable Polyester / die-cast zinc, ensuring longevity in demanding environments. The sensor connects via an Cable, L=2 m, offering easy integration into your system. Unlock Exclusive Pricing with a Quote for your requirement of Baumer PNP NO Ultrasonic Proximity Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
