Baumer UNDK 20P7912/S35A: Level Sensors
Technical Specifications of Baumer UNDK 20P7912/S35A 10156743:
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | PNP break function (NC) |
| Output current | 200 mA |
Baumer Level Sensors UNDK 20P7912/S35A Technical Specifications
| Specification | Value |
|---|
| Output indicator | LED green |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Output circuit | PNP break function (NC) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | Polyester |
| Depth | 15 mm |
| Connection types | Connector M8 |
| Operating temperature | -10 β¦ +60 Β°C |
| Protection class | IP 67 |
| Scanning range Sd | 40 β¦ 400 mm |
| Scanning range far limit Sde | 60 β¦ 400 mm |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Sonic frequency | 290 kHz |
| Adjustment | Teach-in |
| Residual ripple | < 10 % Vs |
| Width / diameter | 20 mm |
| Height / length | 42 mm |
| Alignment aid | Target indication flashing |
| Response time ton | < 25 ms |
| Release time toff | < 25 ms |
