Baumer UNDK 10U6914/S35A: Level Sensors
Technical Specifications of Baumer UNDK 10U6914/S35A 10161448:
| Voltage supply range +Vs | 15 … 30 VDC |
| Output circuit | Voltage output |
| Output current | 20 mA |
Baumer Level Sensors UNDK 10U6914/S35A Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply range +Vs | 15 … 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Output circuit | Voltage output |
| Output current | 20 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | Plastic (ASA) |
| Depth | 14 mm |
| Connection types | Connector M8 |
| Operating temperature | -10 … +60 °C |
| Protection class | IP 67 |
| Scanning range Sd | 20 … 200 mm |
| Scanning range close limit Sdc | 20 … 200 mm |
| Scanning range far limit Sde | 20 … 200 mm |
| Repeat accuracy | 0.5 mm |
| Resolution | < 0.3 mm |
| Temperature drift | > 50 mm < 2 % of distance to target Sde |
| Sonic frequency | 380 kHz |
| Adjustment | Teach-in |
| Light indicator | Yellow LED / red LED |
| Output signal | 0 ... 10 V / 10 ... 0 V |
| Residual ripple | < 10 % Vs |
| Width / diameter | 10.4 mm |
| Height / length | 27 mm |
| Alignment aid | Target indication flashing |
| Response time ton | < 60 ms |
| Release time toff | < 60 ms |
