Baumer FUE 025B1001 Fiber Optic Sensor

Name: Baumer OF10.FR-GW2J.B2CV/A014 11244386
Brand: Baumer
SKU: OF10.FR-GW2J.B2CV/A014
Rating: 4.5 (4 reviews)

The Baumer OF10.FR-GW2J.B2CV/A014 Fiber Optic Sensor offers a operating principle, , and width diameter. Manufactured by Baumer under the Baumer Fiber Optic Sensor category, this model belongs to the FCE Series.

Datasheet

Brand	Baumer
Product Type	Fiber Optic Sensor
Model Number	OF10.FR-GW2J.B2CV/A014

Baumer OF10.FR-GW2J.B2CV/A014 Fiber Optic Sensor – Technical Specifications

Specification	Value
Operating temperature	5 … +55 °C
Response time / release time	0.05 ms (Ultra High Speed Mode), 0.125 ms (High Speed Mode), 0.25 ms (Standard Mode), 1 ms (High Resolution Mode), 4 ms (Long Range Mode), 16 ms (Ultra Long Range Mode)
Light source	Pulsed red LED
Light indicator	OLED display
Wave length	660 nm
Current consumption typ.	30 mA
Voltage drop Vd	<2 VDC
Output function	Light / dark operate switchable
Output circuit	IO-Link / push-pull
Output current	150 mA
Short circuit protection	Yes
Reverse polarity protection	Yes
Width / diameter	10 mm
Height / length	27.8 mm
Depth	82.3 mm
Design	Rectangular
Housing material	Polycarbonate
Connection types	Cable 4 pin, 2 m
Protection class	IP 50

Reach Us by Email for Baumer Fiber Optic Sensors OF10.FR-GW2J.B2CV/A014 Article No: 11244386 at attractive prices. In-depth Technical Analysis of OF10.FR-GW2J.B2CV/A014, 11244386 feature The cable jacket is made of , while the fiber optic cable itself is made of robust for lasting reliability. The total length of the fiber optic cable is .Now's the Time to Secure a Quote for your requirement of Baumer Fiber Optic Sensors OF10.FR-GW2J.B2CV/A014. We're committed to offering more favorable pricing and more responsive support than other Traders.
