O500.GP-PV1T.72O: 11096065 - Baumer Photoelectric Sensor With Visible Light Source
Technical Specifications of Baumer Photoelectric Sensor With Visible Light Source O500.GP-PV1T.72O 11096065:
| Spec | Value |
|---|---|
| Sensing distance Tw | 60 … 400 mm |
| Sensing range Tb | 30 … 400 mm |
| Output circuit | PNP complementary |
| Connection types | Connector M12 4 pin |
Baumer Photoelectric Sensor With Visible Light Source O500.GP-PV1T.72O, 11096065 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 60 … 400 mm |
| Sensing range Tb | 30 … 400 mm |
| Power on indication | LED green |
| Sensing distance adjustment | qTeach |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1° |
| Light source | Pulsed PinPoint LED |
| Wave length | 630 nm |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP complementary |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Depth | 32 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Protection class | IP 67 |
| Operating temperature | -25 … +60 °C |
| Light indicator | LED yellow |
Reach Us by Email for Baumer Photoelectric Sensor With Visible Light Source O500.GP-PV1T.72O part no: 11096065 at Discounted Rates. Key Technical Features of O500.GP-PV1T.72O, 11096065 are Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 60 … 400 mm. The sensor features qTeach adjustment for flexible setup and utilizes an Pulsed PinPoint LED light source with a wavelength of 630 nm. It boasts a fast response time of less than < 0.49 ms, and operates within a voltage supply range of 10 … 30 VDC, with a typical current consumption of 30 mA. The output function supports Light / dark operate with a PNP complementary output circuit and can handle an output current of up to 100 mA. Measuring 18 mm in width, 45 mm in height, and 32 mm in depth, this compact Rectangular sensor is connected via a Connector M12 4 pin. Navigate Your Needs with a Quote for your requirement of Baumer Photoelectric Sensor With Visible Light Source. Our pricing and support are unrivaled, especially when compared to other Competitors.
