Baumer LXC-250C Industrial Camera
The Baumer LXC-250C Industrial Camera offers a 56.5 dB dynamic range, Global shutter, M58-mount (F-mount, M42, C-mount via adapter), and onsemi PYTHON 25K connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
| Brand | Baumer |
| Product Type | Industrial Camera |
| Model Number | LXC-250C |
Baumer LXC-250C Industrial Camera β Technical Specifications
| Specification | Value |
|---|---|
| Sensor | onsemi PYTHON 25K |
| Mono/Color | Color |
| Sensor type | APS-H CMOS |
| Shutter type | Global shutter |
| Resolution | 5120 Γ 5120 px |
| Pixel size | 4.5 Γ 4.5 Β΅m |
| Exposure time | 0.03 β¦ 1000 ms |
| Dark noise | 11.97 e- |
| Saturation capacity | 8560 e- |
| Dynamic range | 56.5 dB |
| Signal-to-noise ratio | 39.3 dB |
| Quantum efficiency | 35.8 % @ 465 nm, 38.9 % @ 536 nm, 39.2 % @ 631 nm |
| Image formats, interface frame rate max. | Full Frame, 5120 Γ 5120 px, max. 32 fps |
| Pixel formats | BayerGB8, BayerGB10 |
| Analog controls | Gain (0 β¦ 23,5 dB), Offset (0 β¦ 63 LSB 10 Bit) |
| Color models | Raw Bayer |
| Color processing | NA |
| Synchronization | free running, trigger |
| Trigger sources | Hardware, Software, ActionCommand |
| Trigger delay | 0 β¦ 2 sec, tracking and buffering of up to 256 trigger signals |
| Internal image buffer | 512 MB |
| Data interface | Camera Link Full, connector: 2 x Standard SDR26 (Mini CL) |
| Process interface | M8 / 8 pins |
| Power supply | via M8 / 8 pins |
| Lens mount | M58-mount (F-mount, M42, C-mount via adapter) |
| Width | 60 mm |
| Height | 60 mm |
| Depth | 45.12 mm |
| Weight | β€ 235 g (M58-mount) |
| Material | housing: aluminum |
| Voltage supply range +Vs | 12 β¦ 24 V DC (external power supply), 38 β¦ 57 V (PoCL) |
| Power consumption | Approx. 7.8 W @ 24 VDC, Approx. 7.8 W @ 12 VDC (PoCL) |
| Flash memory size | 128 kB |
| Operating temperature | #ERROR! |
| Humidity | 10 β¦ 90 % (non-condensing) |
| Protection class | IP 40 |
