Baumer IR08.D02S-F40.UA1Z.7SCV Proximity Sensor
The Baumer IR08.D02S-F40.UA1Z.7SCV Proximity Sensor offers a Cylindrical threaded design, 0 … 2 mm sensing distance, Voltage output output, Flush mounting type, and Cable, L=2 m connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IR08 Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IR08.D02S-F40.UA1Z.7SCV |
Baumer IR08.D02S-F40.UA1Z.7SCV Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Measuring distance Sd | 0 … 2 mm |
| Resolution | < 0.001 mm (stat.), < 0.005 mm (dynam.) |
| Repeat accuracy | 0.02 mm |
| Linearity error | ± 60 µm (S = 0,5 ... 1,5 mm), ± 140 µm (S = 0 ... 2 mm) |
| Temperature drift | ± 3 % (Full Scale: 0 ... +60 °C), ± 5 % (Full Scale: -10 ... +70 °C) |
| Response time (factory characteristic) | < 0.5 ms |
| Voltage supply range +Vs | 12 … 36 VDC |
| Current consumption max. (no load) | 10 mA |
| Output circuit | Voltage output |
| Output signal | 0 ... 10 VDC |
| Load resistance | > 4000 Ohm |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Material (sensing face) | PBT |
| Housing material | Stainless steel |
| Dimension | 8 mm |
| Housing length | 40 mm |
| Connection types | Cable, L=2 m |
| Tightening torque max. | 10 Nm (A: 7 Nm) |
| Operating temperature | -10 … +70 °C |
| Protection class | IP 67 |
Talk to Our Engineer for Baumer Inductive Distance Sensor IR08.D02S-F40.UA1Z.7SCV Article No: 11130472 with exclusive offers. Core System Specifications of IR08.D02S-F40.UA1Z.7SCV, 11130472 are Flush mounting type with a measuring distance of 0 … 2 mm. It delivers < 0.001 mm (stat.), < 0.005 mm (dynam.) resolution, ensuring repeat accuracy of 0.02 mm. The linearity error is ± 60 µm (S = 0,5 ... 1,5 mm), ± 140 µm (S = 0 ... 2 mm), with a temperature drift of ± 3 % (Full Scale: 0 ... +60 °C), ± 5 % (Full Scale: -10 ... +70 °C). The factory-set response time is < 0.5 ms, making it ideal for high-speed applications. It operates within an 12 … 36 VDC voltage supply range, consuming only 10 mA. The Cylindrical threaded design includes a PBT sensing face and an Stainless steel housing for durability. The compact structure has an 8 mm dimension and an 40 mm housing length. It connects via a Cable, L=2 m and operates in temperatures between -10 … +70 °C with IP 67 protection. Don't Miss Out on a Quote for your requirement of Inductive Distance Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
