Baumer FFDK 16P50Y0: Level Sensors
Technical Specifications of Baumer FFDK 16P50Y0 10143978:
| Voltage supply range +Vs | 9 β¦ 30.8 VDC |
| Output circuit | PNP |
| Output current | 100 mA |
Baumer Level Sensors FFDK 16P50Y0 Technical Specifications
| Specification | Value |
|---|---|
| Sensitivity adjustment | No |
| Output indicator | LED red |
| Voltage supply range +Vs | 9 β¦ 30.8 VDC |
| Current consumption max. (no load) | 25 mA |
| Output circuit | PNP |
| Output current | 100 mA |
| Voltage drop Vd | <1 VDC |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | PC |
| Depth | 26 mm |
| Connection types | Cable 3 pin, 2 m |
| Operating temperature | -10 β¦ +55 Β°C |
| Protection class | IP 50 |
| Width / diameter | 16 mm |
| Height / length | 28 mm |
