acA2040-120um: 107206 - Basler Area Scan Camera with 10 Bits Pixel Bit Depth
Technical Specifications of Basler Area Scan Camera with 10 Bits Pixel Bit Depth acA2040-120um 107206:
| Sensor | IMX252 |
| Sensor size | 7.07 mm × 5.3 mm |
| Mount | C-mount |
| Cable Length | 10 m |
Basler Area Scan Camera with 10 Bits Pixel Bit Depth acA2040-120um, 107206 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | ace U |
| Products Line | Standard |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Sony |
| Sensor | IMX252 |
| Shutter | Global Shutter |
| Sensor Format | 2/3" |
| Sensor Diagonal | 8.84 mm |
| Sensor Type | CMOS |
| Sensor Size | 7.07 mm × 5.3 mm |
| Resolution (H x V) | 2048 px × 1536 px |
| Resolution | 3 MP |
| Pixel Size (H x V) | 3.45 μm × 3.45 μm |
| Frame rate | 120 fps |
| Mono/Color | Mono |
| Spectrum | Visible |
| Quantum Efficiency (typical/minimal) | 69 % (typical) |
| Dark Noise (typical/maximal) | 2.3 e¯ (typical) |
| Saturation Capacity (typical/minimal) | 10.5 ke¯ (typical) |
| Dynamic Range (typical/minimal) | 73.4 dB (typical) |
| Signal-to-Noise Ratio (typical/minimal) | 40.2 dB (typical) |
| Interface | USB 3.0 |
| Image Data Interface | USB 3.0, nominal max. 5 Gbit/s (SuperSpeed) |
| Pixel Bit Depth | 10 bits, 12 bits |
| Exposure Control | hardware trigger, programmable via the camera API |
| Digital Input | 1 |
| Power Supply | Via USB 3.0 interface |
| Power Requirements (typical) | 3.1 W |
| Housing Type | Box |
| Housing Size (L x W x H) | 29.3 mm x 29 mm x 29 mm |
| Weight | 80 g |
| Lens Mount | C-mount |
| Operating Temperature | 0 °C - 50 °C |
| Attribute Name | Attribute Value |
| Mount | C-mount |
| Focal Length | 35 mm |
| Working Distance | 200 mm |
| Type | I/O / Power Cable |
| Cable Length | 10 m |
| LED Color | Red |
| Peak Wavelength (typical) | 625 nm |
| Protection Class | IP54 |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 5 Gbps (625 MB/s); 5 Gbps (625 MB/s) |
| Synchronization | free-run, hardware trigger, software trigger |
| Digital Output | 1 |
| General Purpose I/O | 2 |
Please speak to our Technical Engineer for Basler Area Scan Camera with 10 Bits Pixel Bit Depth acA2040-120um part no: 107206 at attractive prices. Technical Specs Summary of acA2040-120um, 107206 includes Product Family offers the ace U and Standard series, featuring a 3 MP resolution at 120 fps. The camera utilizes a USB 3.0 interface and supports Power over Ethernet Via USB 3.0 interface power supply options. Designed for durability, the camera is housed in a robust Box-type enclosure with a C-mount lens interface. It operates efficiently within a temperature range of 0 °C - 50 °C making it suitable for various industrial environments. The focal length is 35 mm with a working distance of 200 mm and a cable length of 10 m. The camera operates at a peak wavelength of 625 nm. Match Your Needs with a Quote for your requirement of Basler Area Scan Camera with 10 Bits Pixel Bit Depth. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
