Home Brands Banner Cordsets STP-M8M-M12DM-0.2 Banner STP-M8M-M12DM-0.2 Cordset The Banner STP-M8M-M12DM-0.2 Cordset offers a Double Ended , M8 connection, 30 V ac/dc rating, and Shield - Tied to Coupling Nut . Manufactured by Banner under the Banner Cordset category.
Brand Banner Product Type Cordsets Model Number STP-M8M-M12DM-0.2
Banner STP-M8M-M12DM-0.2 Cordset – Technical Specifications Specification Value IP Rating IP67 Cable Jacket Color Black Cable Jacket Material PVC Coupling Nut Material Nickel Plated Brass Connector 1 Gender Male Connector 1 Orientation Straight Cordset Length (m) 2 Outside Cable Diameter (mm) 5 Connector 1 Number of Contacts 4 Number of Ends Double Ended Connector 2 Type M12 Connector 1 Type M8 Voltage Rating (V) 30 V ac/dc Minimum Temp. (Celsius) -40 Shield/No Shield Shield - Tied to Coupling Nut Overmold Material and Color PUR Black Current Rating (A) 1 Maximum Temp. (Celsius) 70 Cordset Length Range (m) 2.00-4.99 Connector 2 Number of Contacts 4 Connector 2 Gender Male Connector 2 Orientation Straight Connector 2 Key Code D
