Banner LEDRB70X70M Vision Light
The Banner LEDRB70X70M Vision Light offers a Backlight type, 24 V dc supply voltage, and Pigtail QD connection. Manufactured by Banner under the Banner Vision Light category, this model belongs to the right light Series.
| Brand | Banner |
| Product Type | Vision Light |
| Model Number | LEDRB70X70M |
Banner LEDRB70X70M Vision Light β Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Rectangular |
| Cable Length (m) | 2 |
| Power | DC |
| Primary Housing Material | Low-Carbon Steel |
| Connection | Pigtail QD |
| Color Technology | Standard LED |
| Quick Disconnect Type | M8 |
| Max Current Color (mA) | 250 |
| Number of Input Pins/Conductors | 3 |
| Supply Voltage | 24 V dc |
| Physical Dimensions (LxWxH or DxH mm) | 110.4 x 92.6 x 25.0 |
| High Temperature (up to 100Β° C) | 50 |
| Feature: Quick Disconnect | Yes |
| Device Type | Backlight |
| Connection Type | Pigtail QD |
| QD Type/Cable Length | 2 m; M8 |
| Color | Red |
| Window Material | Acrylic |
