Banner LEDGS50L20 Vision Light
The Banner LEDGS50L20 Vision Light offers a Spot Light type, 12-30 V dc supply voltage, and Cable connection. Manufactured by Banner under the Banner Vision Light category, this model belongs to the right light Series.
| Brand | Banner |
| Product Type | Vision Light |
| Model Number | LEDGS50L20 |
Banner LEDGS50L20 Vision Light β Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Circular Spot |
| IP Rating | IP67, IP69K |
| Cable Length (m) | 2 |
| Power | DC |
| Primary Housing Material | Anodized Aluminum |
| Connection | Cable |
| Color Technology | Standard LED |
| Max Current Color (mA) | 400 |
| Number of Input Pins/Conductors | 5 |
| Supply Voltage | 12-30 V dc |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 49.3 |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -40 |
| Device Type | Spot Light |
| Feature: Washdown Rated | Yes |
| Connection Type | Cable |
| Lens Focusing Angle (Β°)/Field of View | 20 |
| QD Type/Cable Length | 2 m |
| Color | Green |
| Window Material | Acrylic |
