Banner BES36-A0CA0M-4C0ET1E0 Absolute Encoder
The Banner BES36-A0CA0M-4C0ET1E0 Rotary Encoder offers a 10 shaft diameter, Clamp flange type, 15-30 V dc power supply, and Cable connection. Manufactured by Banner under the Banner Rotary Encoder category, this model belongs to the BEH Series.
| Encoder Type | Absolute |
| Supply Voltage | 15-30 V dc |
| Connection | Cable |
Banner Absolute Encoder BES36-A0CA0M-4C0ET1E0 Technical Specifications
| Specification | Value |
|---|---|
| Primary Housing Material | Zinc-Nickel-Plated Steel |
| Encoder Type | Absolute |
| Housing Diameter (mm) | 36 |
| Shaft Diameter (mm) | 10 |
| Solid Shaft | Yes |
| Shaft Material | Stainless Steel |
| Supply Voltage | 15-30 V dc |
| Connection | Cable |
| QD Type/Cable Length | 1 m |
| Environmental Rating | IP54 |
| Rotational Speed (RPM) | 12000 |
| Flange Type | Clamp |
| Flange Material | Aluminum |
| Revolution | 16 |
| Steps/Revolution | 4096 |
| Analog | Yes |
| Resolution | Revolution: 16 , Steps/Revolution: 4096 |
| Axial Shaft Load | 20N |
| Radial Shaft Load | 80N |
