LS2E30-600Q8: 73527 - Banner 600 mm Defined Area Light Curtain
Technical Specifications of Banner 600 mm Defined Area Light Curtain LS2E30-600Q8 73527:
| Spec | Value |
|---|---|
| IP Rating | IP65 |
| Safety Level | Type 2 |
| Connector Type | M12 |
| Dimensions WxD (mm) | 25.4 x 31.8 |
Banner 600 mm Defined Area Light Curtain LS2E30-600Q8, 73527 Technical Specifications:
| Specification | Value |
|---|---|
| IP Rating | IP65 |
| Heavy Duty | - |
| Defined Area Height Range (mm) | >350 - <=650 |
| Max Operating Range (m) | >8 - <=20 |
| Primary Housing Material | Aluminum |
| Safety Level | Type 2 |
| Connector Type | M12 |
| Defined Area Height (mm) | 600 |
| Dimensions WxD (mm) | 25.4 x 31.8 |
| Overall Length (mm) | 665 |
| Housing Finish | Yellow Polyester |
| Number of Pins (Receiver/Emitter) | 8 |
| Operating Distance (m) | 0.2 - 15 |
| Operating Voltage | 24 V dc +/- 20% |
| Operating Temperature | 0 to +55 deg. C; RH 95% |
| Resolution (mm) | 30 |
| Response Time | 16 |
| System Type | Emitter |
| Vibration | 10-55 Hz at 0.35 mm |
| Housing Material | Aluminum; Zinc; Acrylic |
| OSSD Rating | N/A |
| Supply Current | 50 mA max. |
| Auxiliary Output | No |
| Trip/Latch Output | N/A |
Ask for the Pricing of Banner 600 mm Defined Area Light Curtain LS2E30-600Q8 Part no: 73527 at unbeatable prices. Detailed Specifications of LS2E30-600Q8, 73527 feature EZS TYPE2 E TRIP 30 mm x 600 mm, System type is Emitter, Resolution of 30 mm. Response time is 16 ms, IP65 rated. Defined area height range >350 - 8 - <=20. The primary housing is made of Aluminum, classified as Type 2 safety level, and uses an M12 connector. The defined area height is 600 mm, with dimensions of 25 4 x 31 8 mm and an overall length of 665 mm. The housing is finished in Yellow Polyester, with 8 pins in the receiver/emitter and an operating distance from 0 2 - 15 meters. Operating voltage is 24 V dc +/- 20%, with vibration tolerance of 10-55 Hz at 0 35 mm. Auxiliary output is No, with housing materials including Aluminum; Zinc; Acrylic and a supply current of 50 mA max . Now's the Time to Secure a Quote for your requirement of Banner 600 mm Defined Area Light Curtain. We're committed to offering more favorable pricing and more responsive support than other Traders.
