Autonics S16ER-E3R2B24 - 16 mm Emergency Switches
Autonics 16 mm Emergency Switches S16ER-E3R2B24 Technical Specifications
| Brand | Autonics |
| Product Type | Control Switches |
| Product | S16ER-E3R2B24 |
Autonics 16 mm Emergency Switches S16ER-E3R2B24 Technical Specifications
| Specification | Value |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 250VAC~/3A |
| LED block_Power supply | 24VDC @(=) |
| LED block_Current consumption | 15~20mA |
| Illuminated | D30(short head, illuminated) |
| Color | Red |
| Operation type | Push-lock, Turn/Pull-reset |
| Contact block | B contact: 2 |
| Environment_Ambient temperature | -15 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65(IEC standard) |
| Weight_Housing | Approx. 1.4g |
| Weight_Contact block | Approx. 1.6g |
| Weight_LED block | Approx. 1.9g |
| Weight_Body | Approx. 11.5g |
