Autonics PSN40-20AO Proximity Sensor
The Autonics PSN40-20AO Proximity Sensor offers 20mm sensing distance, 60×60×1mm(iron) Standard sensing target, Normally Open, AC 2-wire type100-240VAC~, Frame size 40mm, Standard type(front sensing type) Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PS Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PSN40-20AO |
Autonics PSN40-20AO Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing distance | 20mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 60×60×1mm(iron) |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Open |
| Wire type and power | AC 2-wire type100-240VAC~ |
| Sensing side size | Frame size 40mm |
| Sensing type | Standard type(front sensing type) |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Heat-resistant ABS |
| Response frequency | 20Hz |
| Weight | ≈ 130g (≈ 219g) |
Give Us a Call for Rectangular Inductive Proximity Sensor PSN40-20AO at the lowest pricing. In-depth Technical Analysis of PSN40-20AO feature the key specifications include a sensing distance of 20mm designed for a standard target of 60×60×1mm(iron). This sensor features a Current specification of Leakage current: Max. 2.5mA and a control output with Normally Open configurations. It operates on a Wire type and power AC 2-wire type100-240VAC~. Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70℃, storage: -30 to 80℃ and can be stored at temperatures ranging. A response frequency of 20Hz ensures quick and accurate performance. Elevate Your Project with a Quote for your requirement of Rectangular Inductive Proximity Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
