Autonics PS50-30DN Proximity Sensor
The Autonics PS50-30DN Proximity Sensor offers 30mm sensing distance, 90×90×1mm(iron) Standard sensing target, NPN Normally Open, DC 3-wire type 12-24VDC, Frame size 50mm, Standard type(front sensing type) Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PS Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PS50-30DN |
Autonics PS50-30DN Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing distance | 30mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 90×90×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Open |
| Wire type and power | DC 3-wire type 12-24VDC |
| Sensing side size | Frame size 50mm |
| Sensing type | Standard type(front sensing type) |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Heat-resistant ABS |
| Response frequency | 50Hz |
| Weight | ≈ 220g (≈ 256g) |
Give Us a Call for Rectangular Inductive Proximity Sensor PS50-30DN at the lowest pricing. In-depth Technical Analysis of PS50-30DN feature the key specifications include a sensing distance of 30mm designed for a standard target of 90×90×1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with NPN Normally Open configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC. Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70℃, storage: -30 to 80℃ and can be stored at temperatures ranging. A response frequency of 50Hz ensures quick and accurate performance. Elevate Your Project with a Quote for your requirement of Rectangular Inductive Proximity Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
