Autonics PS08-2.5DP2U Proximity Sensor
The Autonics PS08-2.5DP2U Proximity Sensor offers 2.5mm sensing distance, 8×8×1mm(iron) Standard sensing target, PNP Normally Closed, DC 3-wire type 12-24VDC, Frame size 8mm, Upper sensing type Response frequency. Manufactured by Autonics under the Autonics Proximity Sensors category, this model belongs to the Autonics PS Series.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PS08-2.5DP2U |
Autonics PS08-2.5DP2U Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing distance | 2.5mm |
| Hysteresis(distance) | Max. 20% at sensing distance |
| Standard sensing target | 8×8×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Closed |
| Wire type and power | DC 3-wire type 12-24VDC |
| Sensing side size | Frame size 8mm |
| Sensing type | Upper sensing type |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67(IEC standard) |
| Material | Polycarbonate |
| Response frequency | 1kHz |
| Weight | ≈ 16 g (≈ 30 g) |
Give Us a Call for Rectangular Inductive Proximity Sensor PS08-2.5DP2U at the lowest pricing. In-depth Technical Analysis of PS08-2.5DP2U feature the key specifications include a sensing distance of 2.5mm designed for a standard target of 8×8×1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with PNP Normally Closed configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC. Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70℃, storage: -30 to 80℃ and can be stored at temperatures ranging. A response frequency of 1kHz ensures quick and accurate performance. Elevate Your Project with a Quote for your requirement of Rectangular Inductive Proximity Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
