Autonics PRD12-4DP2 Proximity Sensor
The Autonics PRD12-4DP2 Proximity Sensor features a 4mm sensing distance with PNP Normally Closed output and a compact M12 sensing side diameter for precise and stable detection. Manufactured by Autonics, this Autonics Proximity Sensor under the PRD Series operates on DC 3-wire type 12–24VDC power and ensures IP67 protection structure for dependable industrial use. It supports a 500Hz response frequency and detects 12×12×1mm (iron) standard targets with maximum 10% hysteresis ensuring consistent and accurate performance.
| Brand | Autonics |
| Product Type | Proximity Sensor |
| Model Number | PRD12-4DP2 |
Autonics PRD12-4DP2 Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 4mm |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Standard sensing target | 12×12×1mm(iron) |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Closed |
| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Installation | Shield(flush) |
| Cable Standard/material | Standard cable |
| Body length | Standard type |
| Residual voltage | Max. 1.5V |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Protection structure | IP67 |
| Material | Brass(nickel plated) |
| Response frequency | 500Hz |
| Weight | ≈ 62g (≈ 74g) |
Talk to Our Engineer for Long-Distance Inductive Proximity Sensor PRD12-4DP2 with exclusive offers. Core System Specifications of PRD12-4DP2 are the key specifications include a sensing distance of 4mm designed for a standard target of 12×12×1mm(iron). This sensor features a Current specification of Current consumption: Max. 10mA and a control output with PNP Normally Closed configurations. It operates on a Wire type and power DC 3-wire type 12-24VDC @(=). Its sensing side size guarantees precise detection, even in challenging environments. The sensor operates efficiently within ambient temperatures of -25 to 70℃, storage: -30 to 80℃ and can be stored at temperatures ranging. A response frequency of 500Hz ensures quick and accurate performance. Don't Miss Out on a Quote for your requirement of Long-Distance Inductive Proximity Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
