Autonics MT8C-3ALGB-RYG Tower Light

The Autonics MT8C-3ALGB-RYG Tower Light offers Steady, Flashing, Buzzerfunction, 24VAC/DC power supply, Red, Yellow, Green lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Tower Light category, this model belongs to the Autonics MT8C Series.

Brand	Autonics
Product Type	Tower Lights
Model Number	MT8C-3ALGB-RYG

Autonics MT8C-3ALGB-RYG Tower Light – Technical Specifications

Specification	Value
Function	Steady, Flashing, Buzzer
Power supply	24VAC/DC
Current consumption	1.33A
Lens color	Red, Yellow, Green
Dimension	D86mm
Flashing rate	80±10times/minute
Connection type	Lead wire connection
Cable specification	UL3266/22AWG
Ambient temperature	-15~40℃
Storage ambient temperature	-20~70℃
Ambient humidity	45 to 85%RH
Insulation resistance	100MΩ or more (500VDC megger basis)
Vibration	0.75mm at 10~55Hz
Protection structure	IP50
Buzzer volume	80±5dB (at 1m)
Bulb specification	24V 10W
