Autonics M5W-T-1 Digital Panel Meter
The Autonics M5W-T-1 Digital Panel Meter offers 4½-digit 7-segment LED display method, 14mm character height, 0 to 1999.9 display range, Rotation measurement. Manufactured by Autonics under the Autonics Digital Panel Meter category, this model belongs to the Autonics M5W Series.
| Brand | Autonics |
| Product Type | Digital Panel Meter |
| Model Number | M5W-T-1 |
Autonics M5W-T-1 Digital Panel Meter – Technical Specifications
| Specification | Value |
|---|---|
| Display method | 4½-digit 7-segment LED |
| Character height | 14mm |
| Max. display Range | 0 to 1999.9 |
| Measurement | Rotation |
| Input specification | 0-10VDC |
| Sampling cycle | 300ms |
| Max. allowable input | 150% for each input specification (at 400VAC:120%) |
| Power supply(Option) | 100-240VAC~ 50/60Hz |
| Output | Indicator |
| Display accuracy_DC power | F.S. ±0.2% rdg ±1-digit |
| Environment_Ambient temperature | 0 to 50℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 172g |
Talk to Our Engineer for Autonics Digital Tachometers M5W-T-1 with exclusive offers. Core System Specifications of M5W-T-1 are an 4½-digit 7-segment LED with 14mm character height, these displays support a maximum range of 0 to 1999.9. Designed for Rotation measurement, they handle 0-10VDC inputs. The system supports AVG and RMS measurement methods and operates on 100-240VAC~ 50/60Hz Power supply(Option). Outputs include Indicator and 0 to 50℃, storage: -25 to 65℃Environment_Ambient temperature. The Environment_Ambient humidity is 35 to 85% RH, storage: 35 to 85% RH. The Approx. 172g Weight ensures precise 300ms sampling. Equipped with a 150% for each input specification (at 400VAC:120%), Max. allowable input for industrial automation applications. Get a quote today for Autonics Display Units with superior accuracy and performance. Don't Miss Out on a Quote for your requirement of Digital Tachometers. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
