In most procurement cycles, E20S2-360-3-V-12-S is considered with Autonics Proximity Sensor, Baumer Encoder and Rotary Encoders E50S8 1024 6 L, giving decision-makers confidence that theyβve chosen the most dependable component.
Autonics E20S2-360-3-V-12-S Rotary Encoder
The Autonics E20S2-360-3-V-12-S Rotary Encoder offers Γ2mm shaft outer diameter, 6000rpm Max. allowable revolution, Voltage, Control output 12VDC, Power supply, 360P/R, resolution Radial cable type connection type. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the Autonics E20S Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | E20S2-360-3-V-12-S |
Autonics E20S2-360-3-V-12-S Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Shaft outer diameter | Γ2mm |
| Max. response frequency | 100kHz |
| Max. allowable revolution | 6000rpm |
| Starting torque | Max. 5gf.cm(max. 0.00049N.m) |
| Resolution | 360P/R |
| Output phase | A, B, Z |
| Control output | Voltage |
| Power supply | 12VDC |
| Connection type | Radial cable type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70β, storage: -20 to 80β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Γ2mm coupling |
| Weight | Approx. 35g |
Send Your Inquiry for 20 mm Incremental Rotary Encoder E20S2-360-3-V-12-S with cost-effective solutions. Essential Technical Specs of E20S2-360-3-V-12-S are shaft outer diameter of Γ2mm for precise applications. The encoder supports a maximum response frequency of 100kHz and an allowable revolution speed of 6000rpm, ensuring efficient performance in demanding environments. With a resolution of 360P/R, it provides accurate signal output. The control output is a Voltage, designed to operate seamlessly with a power supply 12VDC. The encoder comes with an Radial cable type connection for easy integration into various systems. Its operational temperature range is -10 to 70β, storage: -20 to 80β. Humidity levels are supported at 35 to 85% RH, storage: 35 to 90% RH during storage. Capture the Best Deal with a Quote for your requirement of 20 mm Incremental Rotary Encoder. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
