Autonics DPU32A-040D 40 A Power Controller
DPU32A-040D is an Autonics 40 A Power Controller for three-phase 220V systems with 40A rated current industrial automation use. Manufactured by Autonics, this controller is part of Autonics Power Controllers within the DPU Series, supporting 0–98% phase control, 0–100% cycle ON/OFF control, ≤ 60 W power consumption, and a remote display unit option.
| Brand | Autonics |
| Product Type | Power Controller |
| Model Number | DPU32A-040D |
Autonics DPU32A-040D 40 A Power Controller – Technical Specifications
| Specification | Value |
|---|---|
| Control input | • Auto: 4-20mA / 0-20mA / 0-5VDC @(=) / 1-5VDC @(=) / 0-10VDC @(=) / voltage pulse (0/12VDC @(=)) / no-voltage input (ON/OFF) / Communication input (RS485)• Manual: inside 10kΩ VR, outside 3 to 10kΩ VR (min. 2W) |
| Control method | • Phase control: Normal control(Non-Feedback), static voltage/static current/static power control(Feedback)• Cycle control (Z.C.): Fixed cycle control, Variable cycle control• ON/OFF control (Z.C.) |
| Output range | Phase control: 0 to 98%, Cycle·ON/OFF control: 0 to 100% |
| Power supply | 220V |
| Power consumption | ≤ 60 W (control power) |
| Environment_Ambient temperature | -10 to 50 ℃, storage: -20 to 80 ℃ (no freezing or condensation) |
| Environment_Ambient humidity | 5 to 90 %RH, storage: 5 to 90 %RH (no freezing or condensation) |
| Indicator | R, S, T indicator (green)Operation / manual control indicator (green)DI, alarm / unit (V, A) indicator (red) |
| Number of phase | 3-phase |
| Load | • Phase control: resistance load, inductive load• ON/OFF, Cycle control: resistance load |
| Rated current capacity | 40A |
| Option | Remote Display Unit |
| Size | 0~70A |
| Unit weight (packaged weight) | ≈ 6.5 kg (≈ 7.6 kg) |
The Autonics DPU32A-040D 40 A Power Controller is designed for regulated power output in industrial automation systems. This model operates on a three-phase 220V power supply with a 40A rated current capacity and supports phase control as well as cycle ON/OFF control. DPU32A-040D belongs to the DPU Series and is applied where controlled electrical load management is required.
The DPU32A-040D Autonics 40 A Power Controller is commonly used in conveyors, packaging machinery, automated production lines, and assembly equipment. Its controlled output range supports stable power regulation for varying industrial loads. The availability of a remote display unit assists operators in monitoring operating status, contributing to consistent performance and reliable integration within control panels.
DPU32A-040D from Autonics delivers defined electrical ratings and controlled power handling aligned with industrial requirements. As part of the DPU Series, it supports three-phase applications with specified output control and managed power consumption. With clear operating parameters, standardized ratings, and integration suitability, the DPU32A-040D Autonics 40 A Power Controller remains a dependable solution for industrial automation use.
