Autonics BTF15-BDTL-P Photoelectric Sensor
The Autonics BTF15-BDTL-P Photoelectric Sensor offers BGS reflective type sensing type, 1 to 15mm, Red LED(650nm), PNP open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BTF Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BTF15-BDTL-P |
Autonics BTF15-BDTL-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | BGS reflective type |
| Sensing distance | 1 to 15mm |
| Sensing target | Opaque, Translucent material(min. sensing target: non-illuminated objects of Γ0.2mm) |
| Response time | Max. 1ms |
| Light source | Red LED(650nm) |
| Operation mode | Light ON |
| Power supply | 12-24VDC |
| Current consumption | Max. 20mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 55β, storage: -40 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67 |
| Connection type | Cable type(Γ2.5, 2m) |
| Material | Case: polybutylene terephthalate, sensing part: polymethyl methacrylate,bracket: SUS304(steel use stainless 304), bolt: carbon steel, sleeve: SUS304(steel use stainless 304) |
| Accessories | Fixing bracket, M2 bolt: 2 |
| Hysteresis(distance) | Max. 5% at sensing distance |
| Weight | Approx. 40g (approx. 25g) |
Autonics developed the BTF15-BDTL-P as part of its Ultra-Compact, Thin Type Photo Sensors range, offering a 1β15mm BGS reflective detection distance. It identifies opaque and translucent materials as small as Γ0.2mm with a 650nm red LED, providing stable operation under factory lighting up to 10,000lx. With a rapid 1ms response, the sensor ensures high-speed accuracy in conveyor and assembly systems. Operating on 12β24VDC at just 20mA, it delivers energy efficiency with PNP open collector output for seamless PLC integration. Its IP67-rated polybutylene terephthalate housing, acrylic optics, and stainless steel accessories guarantee durability even in harsh conditions. Widely supplied by wholesalers, dealers, and distributors, this model is recognized for combining compact design with reliable industrial performance.
The Autonics BTF15-BDTL-P is widely applied in PCB assembly, miniature component inspection, packaging quality checks, and tight conveyor systems. Its slim body makes installation simple where space is limited, while the IP67 rating provides protection against dust, oil, and water spray. Engineers value its fast detection of tiny objects, maintenance teams rely on its low-failure design, and automation students use BTF015 units for training in real-world sensing applications. With proven accuracy and versatility, the BTF15-BDTL-P remains a dependable Photoelectric Sensor for compact automation setups.
Known for precision and durability, the BTF15-BDTL-P stands out among Ultra-Compact, Thin Type Photo Sensors. Its ability to detect small objects quickly with minimal power use makes it a trusted option for industrial buyers across India. Searches for BDTL or BTF015 often lead engineers to this sensor when reliability and compact installation are key requirements. For full specifications, visit the Autonics Photoelectric Sensors section.
