Autonics BS5-P1ML Photomicro Sensor
The Autonics BS5-P1ML Photomicro Sensor offers , sensing distance, Infrared LED(940nm) light source, 12-24VDC power supply, NPN open collector control output. Manufactured by Autonics under the Autonics Photomicro Sensor category, this model belongs to the Autonics BS5 Series.
| Brand | Autonics |
| Product Type | Photomicro Sensor |
| Model Number | BS5-P1ML |
Autonics BS5-P1ML Photomicro Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Connection type | Cable type(Γ3, 1m) |
| Light source | Infrared LED(940nm) |
| Operation mode | Light ON(output OFF when button ispushed) |
| Power supply | 12-24VDC |
| Current consumption | Max. 35mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Fluorescent lamp: Max. 1,000lx(received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP40 |
| Material | Case: Polycarbonate + Glass fiber, Button: Polyoxymethylene, Sleeve: SUS304(steel use Stainless 304) |
| Operation method | Push Button Type |
| Button operation_Stop position | 5.0Β±0.4mm |
| Button operation_Output switching position | 4.0Β±0.5mm |
| Button operation_Operation limit position | Max. 0mm |
| Operation load | Max. 3N(Max. 0.3kgf) |
| External input_Response | Max. 1ms |
| Weight | Approx. 50g(approx. 30g) |
The Autonics BS5-P1ML Push Button Type Photomicro Sensor is engineered for Light ON mode, where the output stays OFF when the button is pressed. Its infrared LED (940nm) ensures stable operation even under 1,000lx fluorescent light. The tactile button mechanism features a 4.0 Β± 0.5mm switching point and a max. 3N operation load, providing accurate detection for human-triggered actions or fixture confirmations.
Powered by a 12β24VDC Β±10% supply and consuming only 35mA, the NPN open collector output integrates easily with PLCs and control systems. The robust polycarbonate + glass fiber housing with SUS304 stainless steel sleeve offers mechanical strength, while the IP40 rating protects against dust ingress. The cable type (Γ3, 1m) connection allows quick installation in tight spaces. For the complete range, visit Autonics Sensors & Controllers.
In assembly plants, it ensures accurate part positioning checks before the next process stage. In packaging units, it acts as a reliable trigger for batch count confirmation or rejection mechanisms. Maintenance teams benefit from its durability and consistent actuation point, reducing calibration needs over time.
For reliable tactile input and long service life in industrial control systems, engineers trust the Autonics BS5-P1ML Push Button Type Photomicro Sensor.
